FA-208 is a very compact two-way line array speaker system with 2x8 "Neodymium LF and 1x 3" Neodymium HF driver units. A drum wave guide is also included. The horizontal constant directivity of 75°can control the lower limit to 400Hz, and the vertical high-frequency diffusion angle of 15°enables FA-208 to be used in a vertical array and generate acurved coherent wave front in front of the array. The mechanical structure of the speakers combined with the acoustic design allows the vertical coupling angle between each speaker to be adjusted between 0°~ 15°. Therefore, according to the different conditions and requirements of users and venues, FA-208 line array can be combined from 2 (15°~ 30°diffusion angle) to 20 speakers. FA-208 cabinet is made from strong marine plywood.The surface of the cabinet is coated with a layer of anti-collision paint.The front panel of the speaker is protected by a strong metal shed. Meanwhile,it is covered with a layer of replaceable acoustic foam material. The side panel is integrated-pair of handles, and the rear panel is embedded with NL 4 parallel interface. Internal and external frequency division processing mode conversion design.
System Type | Double 8 inch line array speaker |
Frequency range | 55Hz-20kHz |
Component Configuration | LF: 2 × 8" Neodymium LF |
HF: 1 × 3" Neodymium HF | |
Rated Power (RMS) | LF: 450W |
HF: 120W | |
Nominal Impedance | LF/HF: 8 Ohm |
Sensitivity(1W/1m)db | 102dB (1w@1m) |
Maximum Peak SPL | 136dB (Pmax@1m) |
Dispersion(-6dB) | 110° H × 10° V |
Connectors | SPEAKON NL4×2 |
Finish | Polyurea coating |
Cabinet | birch plywood |
Dimensions (L x H x D) | 730 x 250/164 x 482 mm |
Weight | 26KG |
Model | FB-18S |
Bass | 1×18" |
Frequency response range | 32Hz-128Hz |
Impedance | 8 Ohms |
Rated power | 700W |
Peak power | 1400W |
Maximum sound pressure SPL | 138dB |
Box structure | imported birch wood |
Cabinet surface treatment | polyurea waterproof paint |
Net weight | 52Kg |
Physical size (L*H*W) | 750×540×707mm |
