Best Line Array Speakers
Product description
FA-110 / FA-110P (active)is a line array consists of one 10" Neodymium LF, one 3" Neodymium HF compression drivers. It's specialized in high-performance and low-distortion compression driver with innovative horn design of waves phase philosophy. Each enclosure is equipped with rigging system, ensure line array system to be constructed rapidly and safely. FA-110 / FA-110P is very versatile and scalable for a wide range of applications in mobile performances, corporate and fixed installation venues.
| Model | FA-110 & FA-110P(active) |
| Type | Line array system |
| Frequency Response | 65Hz-18KHz±3dB |
| Power handling | LF 300W(RMS)600W(PEAK) |
| HF 160W(RMS)320W(PEAK) | |
| Max@S. P.L | LF 130dbSPL peak |
| HF 138dbSPL peak | |
| Sensitivity | LF 100dbSPL |
| HF 113dbSPL | |
| Nominal impedance | 16 ohm |
| LF section | 1×10" Neodymium LF |
| HF section | 1×3" Neodymium HF |
| Nominal impedance | 16ohm |
| Qutput section... | 2-channel |
| Dispersion pattern | 110°H×15°V |
| Paint | Black wearproof polyurea paint |
| Speaker cables | 1(+)1(-) 2(+)2(-) |
| Input connectors | 2×NL4MP speakon ( LF±1 HF±2) |
| Dimensions | 630×300×460mm(W×H×D) |
| Enclosure | 15/18mm Birch Plywood |
| Gross weight | 23kg |
