Model | F-15M&F-15MP(active) |
Type | Two-way,full range monitor system |
Frequency Response | 48Hz-18KHz±3dB |
Power handling | 500W( RMS )1000W(PEAK) |
Sensitivity | 100db(1W/1M) |
Max@S.P.L | 126db(PEAK/1M) |
LF section | 15" (380mm)woofer 75mm(3 inch)coil |
HF section | 3"compression driver with |
75mm titanium diaphragm | |
Nominal impedance | 8 ohm |
Output section | 2-channel |
Dispersion pattern | 60°H x 40°V |
Surface finish | Black Emery water paint |
Speaker cables | 1(+)1(-) |
Input connectors | 2xNL 4MP speakon |
Dimensions | 740 x361 x 533 mm (WxHxD)0.22cbm |
Enclosure | Plywood |
Net weight | 32.5kg(F-15M); 33.5kg(F-15MP) |
Gross weight | 36.5kg(F-15M); 37.5(F-15MP) |
